Acrel AKH-0.66 K-φ24 Split core Current Transformer

● Measurement: Alternating Current (AC)

● Installtion: Split-core type/clamp on installation

● Primary Current Input: 150~300A AC
● Secondary Current Output: 1A/5A

● Accuracy: Class 1

● Rated Operating Voltage: 660V AC

● Rated Frequency: 50~60Hz

● Operating Temperature: -30℃~+60℃

● Operating Altitude: ≤3000m
● Power Frequency withstand Voltage: 3000V/1min 50Hz

● Standard&Certificate: CE

008618702112136

sherry@acrel.cn

8618702112136

Acrel AKH-0.66 K-φ24 Split core Current Transformer

description1

Zipper closure 1/5 zip athletic pullovers for men. Stretchy, lightweight, fast-drying fabric for superior performance. REGULAR FIT - US standard sizes. An athletic fit that sits close to the body for a wide range of motion, designed for optimal performance and all day comfort. FEATURES - Quarter zip closure;Thumbholes on long sleeves to keep them in place during workout

Description

Series Overview

Model Name	Primary Input	Secondary Output	Accuracy Class	Rated Load	Perforation Hole Size (mm)
AKH-0.66/K-φ16-U	20~120A	100~333mV	0.5	10Ω	φ16
AKH-0.66/K-φ16-M	20~120A	10~50mA	0.5	10Ω	φ16
AKH-0.66/K-φ24-U	100~400A	100~333mV	0.5	10Ω	φ24
AKH-0.66/K-φ24-M	100~400A	20~100mA	0.5	10Ω	φ24
AKH-0.66/K-φ24-A	150~200A	5A	1.0	1VA	φ24
AKH-0.66/K-φ24-A	250~300A	5A	1.0	1.5VA	φ24
AKH-0.66/K-φ24-B	150~200A	1A	1.0	1Ω	φ24
AKH-0.66/K-φ24-B	250~300A	1A	1.0	1.5Ω	φ24
