Acrel ANet-1E2S1-4G Smart IoT Gateway
● Double wide voltage (DC / AC 85V ~ 265V) reverse connection protection
● Support 2G/3G/4G
● Support local and remote configuration maintenance and real-time data monitoring
● Max.64 device data collection,support MODBUS-RTU or MODBUS-TCP device
● Support breakpoint continuation,Xml, Json for data transmit
● Support standard 8GB SD card (Max. 32GB)
● Multiple alarm setting for each device
Front Panel
Wiring
Connection
|
Hardware |
|
|
Technical Data |
Index |
|
Processing Element |
ARM32 digit Free scale ARM9 i.MX2xx 454MHz |
|
Inner Board Memory |
64MB DDR2 internal memory + 128MB NAND Flash + 8G SD Card Electronic hard disk |
|
Serial Interface |
Two channels coupling isolation RS485 |
|
Ethernet Interface |
1 channel 10/100 self-adaption capacity |
-
EMC
-
Anet Manual
